- Shortly Description :
These EM4200 RFID Proximity Cards are designed for access control and feature offset printing and silkscreen printing. The cards are designed with a solid gold background and a glossy finish, with gold foil detailing for added elegance. The EM4200 chip ensures that the cards are read-only, with a 128-bit unique code stored in laser-programmed ROW for added security and accuracy of your data. These cards are ideal for applications that require reliable and secure identification. These RFID contactless cards are an excellent choice for access control, attendance management, and other applications that require reliable and secure identification.
In additional, we offer free design services to help you create a customized design that meets your specific needs. Whether you need offset printing, silkscreen printing, or other finishing options, we can provide you with the high-quality cards you need to keep your business running smoothly.
Product Details :
| Iterm | EM4200 Chip RFID Proximity Cards |
| Card Type | Proximity Cards (Contactless Cards ) |
| Size | 85.5*54MM or demand |
| Thickness | 0.86MM or as your need |
| Material | PVC ,PET ,PETG,ABS |
|
Chip |
EM4200 ( compatible with TK4100 ) |
| Frequency |
125KHZ |
| Protocol |
ISO7815 |
| Working Temperature |
-20 ~ +65℃ |
| Reading Distance |
1-10cm |
|
Data life |
10 years |
| Read /Write |
100000 Times |
| Available Crafts | Silver/Gold background , hot foil ( Gold /silver /laser /green /red /rainbow foil or demand ),magnetic stripe ,signature panel ,scratch off , Barcode ,anti-fake , UV spot ,UV ink, engraving /embossed numbering or customized |
- Applications :
- Animal Identification according to ISSO11785 (FDX -B)
- Waste management standard (BDE)
- Access control system
- Logistics automatic
- Anticounterfeiting
- Industrial transponder
- Hotel key card
- School ID cards
- Membership system
- Features:
- Full compatible with EM4100/4102 and EM4005/4105 communication protocols
- 128 bit laser programmed ROW (64 and 96 bit option available )
- Several options Of data rate NDA data encoding :
-Biphase 32 and 64 RF clocks per bit
-PSK 16RF clocks per bit (subcarrier RF/2 )
-PSK 2 50RF clocks per bit
- Several resonant capacitor integrated on chip (0pF,75pF or 250pF mack option)
- 100 to 150KHz frequency range
- On-chip rectifier and voltage limited
- No external supply buffer capacitor needed
- -40℃ to +85℃ temperature range
- Vary low power consumption And high performance
